CENAVA CXS10C 10 Inch Screen Windows Rugged Tablet 6000mAh

Name: CENAVA CXS10C 10 Inch Screen Windows Rugged Tablet 6000mAh
Brand: Cenava

Share to :

The CENAVA CXS10C is a 10.1-inch aluminum-alloy industrial tablet designed for existing Windows, Linux and Kylin-based applications. It offers Intel Core i5 or i7 configurations, M.2 SSD storage and project-specific serial, Ethernet, aviation-connector, 4G and GNSS options.

Operating System: Windows 10

CPU: Intel® Core™ I5

RAM/ROM: 4GB + 128GB

Resolution: 10.1 Inch 1920*1200 IPS Screen

Connectivity: Dual-Band 2.4GHz and 5GHz Wi-Fi, supporting 802.11b/g/n.

Camera: Back 13.0MP

Battery: 3.7V/6000mAh

Certification: IP65, 3C, CE, US military standard-810H certification, energy saving certification, ISO quality certification system, ROHS, three-proof salt spray test

Chat Now Inquiry

Technical Specifications

CPU Intel I5	System Windows 10	Storage 4GB+128G	Display 10.0 inch I10 point full fit screen 1920*1200 500Nit/1000Nit Optional anti glare, waterproof, and glove touch screen support
Speaker Waterproof dual speaker	Fingerprint identification Optional	Battery Built in polymer battery6000mAh	Pilot lamp Always turn on and charge the breathing light
Navigation positioning GPS	Key On/Off key, brightness+/- key H custom function key	Interface HDMI、USB3.0、Gigabit Ethernet port Customizable multiple serial ports, multiple network ports, aviation plugs, and built-in functional modules	Weight 27518523.5mm1.41KG
Card slot TF 512GB	Protection level Working temperature: -20 °C to 50 °C Storage temperature: -40 °C to 70 °C Protection level: IP65	Camera Rear camera:13MP	Sensor Gravity induction

High resolution and brightness anti scratch screen

1920 * 1200 high resolution can bring a visual feast of the sea and sky

Two different brightness options available for 500Nit/1000Nit

IPS anti scratch screen, protecting the screen from damage

CXS10C 6000mAh Rugged Tablet Details:

Product	10.1 inch Rugged tablet
Material	Aluminum alloy CNC precision shell, silicone protective corner, waterproof rubber strip
Screen Size	10.1"Full fit screen
screen resolution	1920*1200
screen brightness	500Nit
TP touch screen	10-point touch capacitive touch screen
Battery	Built-in polymer battery, working time ≥ 3 hours, standby time: 120 hours (5 days); 6000mAh
Camera	Rear 13MP Camera
speaker、MIC	Built-in dual stereo speakers Built-in microphone
CPU	Intel® Core™ I5
GPU	2 cores 4 threads 4M cache, up to 2.60-3.40 GHz
graphics card	Intel® HD Graphics 520；
RAM	DDR4: 4G
SSD	M. 2 2280 SSD:128G
Operating system	Windows 10
WIFI	Dual-Band 2.4GHz and 5GHz Wi-Fi, supporting 802.11b/g/n.
Bluetooth	Bluetooth 4.0
4G（optional）	4G full Netcom, communication network
Positioning system （optional）	Built-in GPS positioning
USB interface	USB3.0*2
Earphone Jack	*1
SIM Card	*1
HDMI	*1
DC interface	*1
RJ45（Gigabit）	*1
power supply	19V-3.5A（5.5x2.1mm）
Certification	IP65, CE, US military standard-810H certification, energy saving certification, ISO quality certification system, ROHS, three-proof salt spray test
drop height	100cm laminate wood floor On state

Frequently Asked Questions About the CXS10C Industrial Tablet

1.What is the processor in the CXS10C?

The standard configuration for the CXS10C is offered with an Intel Core i5-6200U processor, but an Intel Core i7-6600U is also available.

2. Can the CXS10C be deployed for long periods of time?

The i5-6200U has been dropped and both the processors listed are older sixth-generation Intel Core processors.

3.What operating systems do you have?

Windows 10

4. What configurations are there for memory and storage?

The page offers a range of 4GB to 32GB for memory and a range of 128GB to 2TB for M.2 SSD.

5. Are there multiple serial and Ethernet ports that can be added?

The CXS10C allows for customization for the project with serial, Ethernet and aviation connectors. Before production, the protocol, connector, isolation, pin definition, operating-system driver, enclosure drawing and final IP rating shall be approved by the buyer.
